According provided by lens SMC PENTAX-M 1:1.4 50mm Asahi OPT. CO., Japan many thanks to the store FOCUSFILM (subscribe to INSTAGRAM, check out olx). There you can find many interesting film cameras and manual lenses.
SMC PENTAX-M 1:1.4 50mm Asahi OPT. CO., Japan. increase.
In short
SMC PENTAX-M 1:1.4 50mm Asahi OPT. CO., Japan - a good classic manual high-aperture fifty kopeck piece from a bygone era. There is a whole family of such lenses, in which there are approximately 8-9 main models.
Nowadays SMC PENTAX-M 1:1.4 50mm Asahi OPT. CO., Japan is interesting for the 'legendary pattern' common to all similar Takumar/Pentax 50/1.4 lenses, compact size and high aperture.
All lenses of this family (except for the first and the last) use the same optical scheme of 7 elements in 6 groups (classic planar scheme [Planar]). The first was'Planar killer'and used an advanced scheme for those times 8/6 (difference between 7/6 and 8/6), and last - super-modern circuit 15/9!.
This SMC PENTAX-M 1:1.4 50mm Asahi OPT. CO., Japan refers to the 'PENTAX-M' with Pentax K mount.
In parallel with the '50 / 1.4' line, the Pentax / Takumar lens lines of the 50 / 1.7, 50 / 1.8, 50 / 2, 55 / 1.8, 55 / 1.9, 55 / 2, 55 / 2.2, 58 / 2, 58 / 2.4 classes developed and 50/1.2.
It's important: This lens does not suffer from lens coating degradation. For example older versions like Super-Multi-Coated TAKUMAR 1: 1.4 / 50 ASAHI OPT. CO., JAPANsuffered from severe degradation of enlightenment.
SMC PENTAX-M 1:1.4 50mm Asahi OPT. CO., Japan. Aperture blades are visible.
All major versions of similar lenses Asahi Opt. Co., Takumar / Pentax:
1.2/50
- SMC PENTAX 1: 1.2 / 50 ASAHI OPT. CO., JAPAN (7/6, 20947, 1975-1984)
- SMC PENTAX 1:1.2/50 ASAHI OPT. CO.,JAPAN'GOLD' (7/6, 1981)
- SMC PENTAX-A 1: 1.2 50mm (7/6, 20987, 1984-2004)
- SMC PENTAX-A 1: 1.2 50mm Special (7/6, 2000)
1.4 / 50 (video)
- Super takumar 1: 1.4 / 50 Asahi Opt. Co., Lens made in Japan (8/6, 358, 1964-1966)
- Super takumar 1: 1.4 / 50 Asahi Opt. Co. Lens made in japan (7/6, 37800, 1965-1971, F/2 in number)
- Super takumar 1: 1.4 / 50 Asahi Opt. Co. Lens made in japan (7/6, 37801, 1965-1971, F/2 dot)
- Super takumar 1: 1.4 / 50 Asahi Opt. Co., Lens made in Japan (7/6, 37802, 1965-1971, comma after 'CO.')
- Super-Multi Coated TAKUMAR 1: 1.4 / 50 ASAHI OPT. CO., JAPAN (7/6, 37902, 1971-1972)
- SMC TAKUMAR 1: 1.4 / 50 ASAHI OPT. CO., JAPAN (7/6, 37908, 1972-1975)
- SMC PENTAX 1: 1.4 / 50 ASAHI OPT. CO., JAPAN (7/6, 20847, 1975-1977)
- SMC PENTAX-M 1: 1.4 50mm ASAHI OPT. CO., JAPAN (7/6, 20867, 1977-1984)
- SMC PENTAX-A 1: 1.4 50mm (7/6, 20887, 1984-1989)
- SMC PENTAX-F 1: 1.4 50mm (7/6, 20827, 1987-1991)
- SMC PENTAX-FA 1: 1.4 50mm (7/6, 20817, 1991-2023)
- HD PENTAX-D FA * 1: 1.4 50mm SDMAW (15/9, 21260, 2018->)
- SMC PENTAX-FA 1: 1.4 50mm Classic (7/6, 2023->)
- HD PENTAX-FA 1: 1.4 50mm (7/6, 2023->)
1.8 / 55 (video)
- takumar 1:1.8 f=55mm Asahi OPT. CO., Japan (6/5, 1958, zebra)
- Auto-takumar 1:1.8 f=55mm Asahi OPT. CO., Japan (6/5, 1958-1960, zebra)
- Auto-takumar 1:1.8/55 ASAHI OPT. CO., Lens made in Japan (6/5, 1960, with 'R')
- Auto-takumar 1:1.8/55 ASAHI OPT. CO., Lens made in Japan (6/5, 1960-1962, no 'R', oblique lines of the depth of field)
- Auto-takumar 1:1.8/55 ASAHI OPT. CO., Lens made in Japan (6/5, 1962, no 'R', straight lines of depth of field)
- Super takumar 1: 1.8 / 55 Asahi Opt. Co., Lens made in Japan (6/5, 1962, fine ribs, f/1.8 left)
- Super takumar 1: 1.8 / 55 Asahi Opt. Co., Lens made in Japan (6/5, before 1965, fine ribs, f/1.8 right)
- Super takumar 1: 1.8 / 55 Asahi Opt. Co. Lens made in japan (6/5, 37106, before 1971, large ribs)
- Super-Multi Coated TAKUMAR 1: 1.8 / 55 ASAHI OPT. CO., JAPAN (6/5, 37104, 1971-1972)
- SMC TAKUMAR 1: 1.8 / 55 ASAHI OPT. CO., JAPAN (6/5, 37108, 1972-1975)
- SMC PENTAX 1: 1.8 / 55 ASAHI OPT. CO., JAPAN (6/5, 20747, 1975-1977)
2 / 55 (1.9 / 55)
- Auto-takumar 1:1.9 f=55mm Asahi Opt. Co.,Japan (6/5, 1958-1959)
- Auto-takumar 1: 2 f = 55mm Asahi Opt. Co., Japan (6/5, 1958-1959, zebra)
- Auto-takumar 1: 2 f = 55mm Asahi Opt. Co., Japan (6/5, 34100, 1958-1959)
- Super takumar 1: 2 / 55 Asahi Opt. Co., Lens made in Japan (6/5, small fins, F/2 left)
- Super takumar 1: 2 / 55 Asahi Opt. Co., Lens made in Japan (6/5, small ribs, F/2 on the right)
- Super takumar 1: 2 / 55 Asahi Opt. Co. Lens made in japan (6/5, 37103, 1962-1973, large ribs)
- Super takumar 1: 2 / 55 Asahi Opt. Co. Lens made in japan (6/5, 37107, additional aperture pins)
- SMC TAKUMAR 1: 2 / 55 ASAHI OPT. CO., JAPAN (6/5, 37109, 1973-1975)
- SMC PENTAX 1: 2 55mm ASAHI OPT. CO., JAPAN (6/5, 1976-1977)
1.7/50
- SMC PENTAX-M 1: 1.7 50mm ASAHI OPT. CO., JAPAN (6/5, 20877, 1977-1984)
- SMC PENTAX-A 1: 1.7 50mm (6/5, 20897, 1984-1989)
- SMC PENTAX-F 1: 1.7 50mm (6/5, 20837, 1987-1991)
- SMC PENTAX-FA 1: 1.7 50mm (6/5, 20907, 1991-2004)
2/50
- SMC PENTAX-M 1:2 50mm ASAHI OPTICAL CO. (5/5, 20677, 1979-1985)
- SMC PENTAX-A 1: 2 50mm (5/5, 20697, 1985-1998)
2.2/55
- takumar 1:2.2/55 Asahi Opt. CO., Japan (6/5, 1961-1963)
- Auto-takumar 1:2.2/55 ASAHI OPT. CO., Lens made in Japan (6/5, 1961-1963)
2/58
- takumar 1:2 f=58mm Asahi Opt. Co., Japan (6/4, 1957-1958)
- takumar 1: 2 f = 58mm Asahi Opt. Co., Japan (6/4, 1957-1958, labeled 'R')
DA (APS-C: 1.4/55 DA* + 1.8/50 DA)
- SMC PENTAX-DA * 1: 1.4 55mm SDM (9/8, 21790, 2008->)
- SMC PENTAX-DA 1: 1.8 50mm (6/5, 22177, 2012->)
Asahi-Kogaku (M37x1, 3.5/50 + 2.4/58 -> M42)
- takumar 1: 3,5 f = 50mm Asahi-kogaku (4/3, 1952, M37×1)
- takumar 1: 3.5 f = 50mm Asahi-kogaku (4/3, 1952, , M37×1, pre-set)
- takumar 1: 2.4 f = 58mm Asahi-kogaku (5/3, 1954, M37×1, silver)
- takumar 1: 2.4 f = 58mm Asahi Opt. Co., Japan (5/3, 1957-1958, M42)
The lens names in this list correspond exactly to the lens name label on the lens barrel (except for the serial number and/or filter diameter).
SMC PENTAX-M 1:1.4 50mm Asahi OPT. CO., Japan
Main technical characteristics of SMC PENTAX-M 1:1.4 50mm Asahi OPT. CO., Japan:
| Review Instance Name | SMC PENTAX-M 1:1.4 50mm Asahi OPT. CO., Japan |
| Basic properties |
|
| Front Filter Diameter | 49 mm, metal thread for filters |
| Focal length | 50 mm |
| Zoom ratio | 1 X (this is a fixed lens, it does not have a zoom). |
| Designed by | for film cameras with a frame size of 24 x 36 |
| Number of aperture blades | 8 petals. Petals dark matte
At values from F / 2 to F / 2.8, the aperture blades form a hole with small notches |
| Tags |
|
| Diaphragm | from f / 1.4 to f / 22.
The lens has an aperture control ring. The ring has marks for F/1.4, 2, 2.8, 4, 5.6, 8, 11, 16, 22. You can set one additional value between each pair of numbers (except F/1.4->F2 and F/16->F /22). |
| MDF | 0.45 meters, maximum magnification ratio 1:6.7 |
| The weight | 235 grams (measured) |
| Optical design | 7 elements in 6 groups
The same optical design is used by older lenses of this family:
and newer:
|
| Lens hood | Threaded, screwed into the front filter thread |
| Manufacturer country | LENS MADE IN JAPAN (inscription on the body, the lens is made in Japan) |
| Period | 1977-1984. Subsequently replaced by SMC PENTAX-A 1: 1.4 50mm |
| Price | About 100 cu for used option. |
Lenses based on the same optical scheme as the SMC PENTAX-M 1:1.4 50mm Asahi OPT. CO., Japan (from this review, produced from 1972 to 2018 (almost 50 years). The first was a manual SMC TAKUMAR 1: 1.4/50 ASAHI OPT. CO., JAPANand the last one is autofocus SMC PENTAX-FA 1: 1.4 50mm.
SMC PENTAX-M 1:1.4 50mm Asahi OPT. CO., Japan
Assembling, focusing
SMC PENTAX-M 1:1.4 50mm Asahi OPT. CO., Japan is well assembled. Separately, it is worth noting the small size and diameter of the light filter by 49 mm.
The focus ring has an anti-slip insert made of very rough material, rotates approximately 225 degrees (5/8 of a full turn). The course of the ring is very smooth, oily, pleasant. During focusing, the front retractable part of the body does not rotate. Focusing occurs by moving the entire lens block.
The lens uses a Pentax K mount and can be mounted on any modern Pentax digital SLR camera with a K mount.
The front lens shimmers with vibrant hues: red/pink, blue/cyan and purple.
SMC PENTAX-M 1:1.4 50mm Asahi OPT. CO., Japan
Sample photos (APS-C)
The pictures in the gallery above were taken with a camera Pentax K10D (camera view).
All photos in the gallery above are shown without processing. Camera used Sony a3500 (Sony Exmor APS-C HD CMOS sensor at 20 MP). All photos are in-camera JPEG, technology ZEROJPEG. Some photos suffered due to the effect bokeh degradation at fast shutter speeds and wide apertures during EFCS (Y Sony a3500 EFCS cannot be turned off). camera used with adapter Pentax K -> Sony E (NEX).
Source photos can download / watch this link (Google Drive Gallery).
SMC PENTAX-M 1:1.4 50mm Asahi OPT. CO., Japan
Sample photos (Full Frame)
The pictures in the gallery were taken with a camera Canon EOS 5D (Full Frame, 13 MP) and adapter Pentax K -> Canon EF. Technology ZEROJPEG. Sample photos, specially for this review, prepared Natalia (Instagram). Some of the photographs were taken using macro rings for Canon EF, as SMC PENTAX-M 1:1.4 50mm Asahi OPT. CO., Japan can catch a mirror with its long protrusions from the side of the bayonet Canon EOS 5D with normal adapter Pentax K -> Canon EF, macro rings remove this problem.
Source photos can download / watch this link (Google Drive Gallery).
SMC PENTAX-M 1:1.4 50mm Asahi OPT. CO., Japan
